Image thumbnail 3
To:
CC:

S-A HLD62B500L BRKR HLD6 2P 600V 50

Manufacturer: Siemens | Catalog # HLD62B500L | QED Part # 4987282
$2,315.85 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 10 days
Primary Spec Sheet
SIEMENS LOW VOLTAGE SENTRON MOLDED CASE CIRCUIT BREAKER WITH THERMAL - MAGNETIC TRIP UNIT. ASSEMBLED STANDARD 40 DEG C BREAKER LD FRAME WITH HIGH BREAKING CAPACITY. 500A 2-POLE (35KAIC AT 600V) (65KAIC AT 480V). INTERCHANGEABLE TRIP UNIT. SPECIAL FEATURES: LINE AND LOAD SIDE LUGS (TA2J6500) WIRE RANGE 3/0AWG - 500KCMIL (CU) / 4/0AWG - 500KCMIL (AL). DIMENSIONS (W x H x D) IN: 7.50 x 11.0 x 4.00.

Technical Information

Actuator
Varying
Applications
Standard 40C Breaker
Enclosure
Varying
Frame
LD
Interrupt Rating
35 kAIC
Load Rating
N/A
Number of Poles
2 Pole
Operating Temperature
40C
Tc Connection
Line/Load lugs installed
Trip Range
3000-6000
Trip Type
Thermal-Magnetic
Type
HLD6
Voltage
600//250 VAC//VDC

Manufacturer Information

Brand
Siemens
Sub Brand
Sentron

General Product Info

12-Digit UPC
783643008588
Product UPC
78364300858
Weight
17.500 lb

Dimensions

Height
7 Inch
Length
13 Inch
Width
9.000 in

Certifications and Compliance

Country of Origin
Mexico
