Pass & Seymour FB1-TR-DR-N 4.75" x 3.25" x 4" 20.5 cu.in 1-Gang Duplex Receptacle Floor Box Assembly - Nickel

Manufacturer: Legrand Pass & Seymour | Catalog # FB1TRDRN | QED Part # 4406281
$147.61 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Primary Spec Sheet Product Brochure Installation / Instruction Manual
Tamper-Resistant Floor Box Assembly, #8 duplex opening. Two threaded screw plugs,Includes 3232 15 amp, 125 volt tamper-resistant receptacle. Brass. For detailed Tamper-Resistant receptacle information, visit our Tamper-Resistant Receptacles page.

Technical Information

Applications
For Residential/Commercial
Indoor Outdoor
Indoor
Material
Thermoplastic
Mounting Type
Floor
Number of Gangs
1 Gang
Number of Outlets
1
Size
5.25"
Type
1-Outlet, Duplex, Tamper-Resistant Receptacle

Manufacturer Information

Brand
Pass & Seymour
Sub Brand
Pass & Seymour

General Product Info

12-Digit UPC
785007108729
Color
Brass Nickel
Product Series
Slater
Product UPC
78500710872

Dimensions

Depth
4 Inch
Height
4-3/4 Inch
Length
4-3/4 Inch
Warranty Length
1 yr
Width
5-1/4 in

Certifications and Compliance

Certifications
CULUS
Country of Origin
Mexico
Certifications
  • cULus Listed
Features
  • Tamper-Resistant shutters let plugs in, keep other things out.
  • Rugged diecast cover plates.
  • Meets UL514(c) and NEC 314.27(c).
  • Scrub water compliant.
  • With durable nickel or brass cover plates.
  • Dual-voltage models available.
  • Swing brackets mounting option eliminates drilling tile flooring for mounting screws.
  • Wood sub-floors only.
  • Wire Fill (AWG): 10 No. 14, 9 No. 12, 8 No. 10.
