Image thumbnail 4
To:
CC:

Siemens LF211NR GDPS FUS 2P3W 120V 30A

Manufacturer: Siemens | Catalog # LF211NR | QED Part # 4128638
$121.98 /ea
ea
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 10 days
Primary Spec Sheet
Siemens Low Voltage Circuit Protection General Duty Safety Switches. Type: ENCLOSED, SAFETY SWITCH Std: UL V. Rating: 240V A. Rating: 30A No. Of Poles: 2P F. Rating: 60Hz Action: SINGLE THROW Material: 304SS Enclosure: TYPE 3R. 2-3 point mounting holes. O. Cycles: 10000 O. Temperature: (-20F-120F) AMBIENT TEMPERATURE Environmental Conditions: OUTDOOR

Technical Information

Action
SINGLE THROW
Actuator
SINGLETHROW
Ambient Temperature
-29 degrees C
Amperage
30 Amp
Applications
DISCONNECTINGMEANFORSERVICEENTRANCE/LOADS
Enclosure
NEMA3R
Frequency
60 Hz
Insulated?
No
Material
304SS
Mounting Type
2 or 3 Point Mounting Holes
NEMA Size
3
Net Weight
3,66 lb
Number of Poles
2 Pole
Operating Cycles
10000
Operating Temperature
-20 To 120 degrees F
Standard
UL
Tc Connection
MECHANICALLUGS
Type
Fusible
Voltage
240 Volt

Manufacturer Information

Brand
Siemens
Sub Brand
VBII

General Product Info

12-Digit UPC
783643335141
Product UPC
78364333514
Weight
3.650 lb

Dimensions

Height
4.35 Inch
Length
8.3 Inch
Width
5.200 in

Certifications and Compliance

Country of Origin
Mexico
