Pass & Seymour 5362-W 20 Amp 125 VAC 2-Pole 3-Wire NEMA 5-20R White Nylon Duplex Receptacle
Product image thumbnail 0
Product image thumbnail 1
$7.89/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Pass & Seymour / Legrand
Mfg Catalog # 5362-W
QED Part # 119371
Duplex

Features

  • Corrosion-resistant, plated and tabbed steel strap locked in to face and back body to resist pulling away from face/body assembly.
  • .032 inch thick, brass, triple-wipe power contacts for lasting retention.
  • Easily accessed break-off, line-contact connecting tab for fast, easy split-circuit wiring.
  • Impact-resistant nylon face.
  • 8 hole internal screw-pressure-plate back wire terminals accept #10 - #14 AWG solid or stranded copper or copper-clad conductors.
  • Terminal compartments isolated from each other for positive conductor containment.
  • Tri-drive terminal and mounting screws.
  • Auto-ground clip assures positive ground.
  • For covering patents, see www.legrand.us/patents.
  • For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.

Specifications

  • Country Of Origin: MX
  • Amperage: 20 A
  • Standard: UL 498
  • Certifications: CULUS,FEDSPEC
  • NEMA Rating: 5-20R
  • Color: White
  • Voltage: 125.0 V
  • Product Line: Pass & Seymour
  • Wire Size: 4 AWG
  • Number of Wires: 3.0
  • Connection: Wire Ground
  • Number of Poles: Double Pole
  • Special Features: Corrosion-resistant, easy access break off tab for fast connection, 8 hole internal screw pressure plate

Certifications

  • cULus Listed: 140596
  • Federal Spec Listed: WC596

Overview

Long Description eHard Use Spec Grade Duplex Receptacle Back & Side Wire 20amp 125volt Yellow
GTiN 00785007536256
Width 1.322 in
Size 3.3 in
Color White
Voltage 125 Volt
Type Receptacles
Material Thermoplastic
Conductor Size 4 AWG
Applications For Hard use
Mounting Type Wall
Depth .780 in
Height 3.281 in
Grade Specification
Country of Origin Mexico
Wire Size 4 AWG
Capacity Duplex
Connection Type Wire Ground, Back and Side Wire
Family Brand Name Pass & Seymour
Certifications CULUS,FEDSPEC
TC Connection Wire Ground
Amperage 20 Amp
Blade Dimensions 3.3 in
Number of Poles 2 Pole
Number of Wires 3
UNSPSC 39121406
Sub Brand Pass & Seymour
UPC 78500753625
NEMA 5-20R
