3M FP-301-1/16-Green-100' Heat Shrink Thin Wall Tubing
Product image thumbnail 0
Product image thumbnail 1
$38.99/c (100 ea)
Usually ships within 7 to 11 Days
ea
Adding...
Order in multiples of 100 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # FP301-1/16-100'-Green-Spool
QED Part # 1264502
Thin Wall

Overview

3M FP-301 is rated for 275(deg)F(135(deg)C) continuous operation. FP-301 tubing is typically used as a shrink-fit electrical insulation over cable splices and terminations. It is also used for lightweight wire harness covering, wire marking, wire bundling, component packaging and fire resistant covering. FP-301 clear tubing provides excellent visibility for component packing. All FP-301 tubing is split resistant, mechanically tough, easily marked and resists cold flow. FP-301 is available in black, white, red, blue, yellow and clear in the standard lengths of 6-inch (15,2 cm) cut pieces, 48-inch (1,21 m) and small (8.5-inch core diameter) spools of 50 (15,24 m) and 100 (30,48 m) feet. Four-foot lengths of green tubing are available in sizes 1/16 inch to 1/2 inch. The Assorted Color Kit has a total of 133 pieces and contains seven colors: black, red, white, yellow, blue, green and clear. The Black Kit contains 102 pieces, all 6" (512,4 mm) lengths (see chart below.)Additional sizes, colors and put-ups are available -please contact your 3M Electrical Products Sales Representative. Application Specifications: UL Recognized and CSA Certified at 600 volts at 257(deg)F(125(deg)C); UL File No. E-39100 and CSA No. 38227. MIL-I-23053/5, Class 1,2. AMS 3636 (Type I) and AMS 3637 (Type II). To Order: Reference specific product size, color and description on the following pages. Example: FP-301-1/4, white 6" (15,2 cm) pieces.

Specifications

  • Tensile Strength: 2400 Pound-Force Per Square Inch
  • Trademark: 3M
  • Recovered Inner Diameter: 1 Inch
  • Family: 3M Heat Shrink Thin-Wall Tubing FP-301
  • Minimum Expanded Tubing I. D.: 1 Inch
  • Tubing Type: Single (Thin) Wall
  • RoHS 2011/65/EU Compliant: Yes
  • Operating Temperature (Celsius): -55 to 135 Degrees Celsius
  • Mil Spec: AMS-DTL-23053/5, Class 1
  • Expanded Inner Diameter: 1 Inch
  • Non-Corrosive: Yes
  • Agency Approvals: CSA, UL Recognized
  • Dielectric Strength: 900 Volt
  • Flammability Rating: UL 224 All Tubing Flame Test
  • Color: Green
  • Length: 100 Linear Foot
  • RoHS EU Comments: RoHS 2011/65/EU compliant without exemption
  • Flame Retardant: Yes
  • Shrink Ratio: 2:1
  • Elongation: 400 %
  • UL File Number: E-39100

Documents

Overview

Family Brand Name 3M
Long Description 3M Heat Shrink Tubing FP-301 offers an outstanding balance of electrical, physical and chemical properties for a wide variety of industrial and military applications. This tubing comes in 100 ft spool and a quantity of 300 ft per case.
GTiN 00051135375914
Length 100 LF
Color Green
Operating Temperature -55 To 135 C
Type Thin-Wall Flexible Polyolefin
Shrink Ratio 2:1
Outside Diameter 0.0625 in
Dielectric Strength 900 V
Max Operating Temperature 275 degrees F
Overall Length 100 ft
Flame Retardant Yes
