Wiremold G6010B 4-3/4 x 1-1/2 x 3-1/2" Gray Steel Multiple Channel Raceway Blank End
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$11.67/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Wiremold
Mfg Catalog # G6010B
QED Part # 136208
Fittings & Accessories

Features

  • This product meets the material restrictions of RoHS

Specifications

  • Special Features: Extra Large Capacity, Complete line of fittings, Wide range of Datacom connectivity options, UL5 and ADA compliant, UL and cUL Listed
  • Product Depth: 3.63 in
  • Product Height: 1.63 in
  • Type: Raceway
  • Voltage: 600.0 V
  • Product Width: 4.75 in
  • Product Volume: 28.11 cu in
  • Application Sector: Commercial
  • Product Weight: 0.61 lb
  • Standard: cULus Listed Surface Metal Raceway: File E41751: Guide RJPR/RJPR7
  • Country Of Origin: US
  • Certifications: ROHS,CULUS,NAFTA
  • Color: Gray
  • Product Line: Wiremold

Certifications

  • RoHS Compliant
  • cULus Listed: E41751
  • NAFTA Compliant

Overview

Long Description The Wiremold 6000 Series Raceway can be used divided for separate wiring circuits or multi-service applications. For large cabling installations, 6000 can be used undivided as headers and feeders or to bring wiring to a specified location. 6000 Series Raceway is ideal for all applications requiring a high cable capacity, dual service steel raceway. Commercial, institutional, and industrial applications all benefit from the 6000 Series rigid steel construction and durable Ivory ScuffCoat finish. 6000 Series Raceway is also ideal for municipalities that require either all steel construction or prohibit nonmetallic cable management systems.
GTiN 00786776088007
Length 4-3/4 in
Finish ScuffCoat
Color Gray
Type Raceway
Material Steel
Product Series 6000
Applications Commercial, Office
Component Type Fittings & Accessories
Country of Origin USA
Family Brand Name Wiremold
Certifications CULUS,NAFTA,ROHS
Outside Diameter 1.5 in
Blade Dimensions 1-1/2 in OD x 4-3/4 in L x 38 mm D
Jacket Color Ivory, Gray
Used With 6000 Series Raceway
Sub Brand Wiremold
Voltage 600 Volt
Width 4.75 in
Depth 3.63 in
Height 1.63 in
Weight 0.61 lb
UPC 78677608800
