Appleton EYF-75 3/4" Explosion Proof Sealing Unilet
Product image thumbnail 0
Product image thumbnail 1
$18.47/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Appleton
Mfg Catalog # EYF-75
QED Part # 1276913
Sealing Fittings

Specifications

General

  • Application: Class I, Divisions 1 and 2: The purpose of seals in a Class I hazardous location is to minimize the passage of gases and vapors and prevent the passage of flames from one electrical installation to another through the conduit system. Seals are required to
  • Color: Gray
  • Finish Type: Powder Epoxy Paint
  • Material: Iron
  • Series: ENY
  • Type: Sealing Fitting
  • UPC: 783936111322

Dimensions

  • Gross Weight with Packaging: 1.34
  • Height: 0.1 in
  • Hub Size: 3/4"
  • Length: 5 in
  • Weight: 0.55 lb
  • Width: 10 in

Certifications and Compliance

  • CSA File Number: LR11716
  • UL File Number: E10514

Logistics

  • Carton Quantity: 5 EA

Hazardous Rating(s)

  • Class I, Divisions 1 & 2, Groups A, B, C, D
  • Class I, Zones 1 & 2, Groups IIC, IIB, IIA
  • Class II, Divisions 1 & 2, Groups E, F, G
  • Class III, Divisions 1 & 2

Overview

Long Description UNILETS EY Series 25 PCT Fill Vertical And Horizontal Conduit Sealing Fitting, Size: 3/4 IN, Material: Malleable Iron, Finish: Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat), Connection: Female Threaded, Turning Radius: 1.
GTiN 00781381135122
Length 5 in
Finish Triple Coat (Zinc Electroplate, Chromate and Epoxy Powder Coat)
Width 10 in
Size 3/4 IN
Color Gray
Type 25% Fill Vertical and Horizontal, Explosionproof, Female
Material Malleable Iron
Product Series ENY
Applications For Use With Threaded Rigid Metal Conduit and IMC
Height 0.1 in
Weight 0.55 lb
Trade Size 3/4 Inch
Family Brand Name Emerson Electric
TC Connection Female Threaded
Hub Size 3/4 in
Used With Threaded Rigid Metal Conduit and IMC
Sub Brand Unilet
UPC 78138113512
